80Plus Bronze Certification
350W-850W Available
140×150×85mm Dimensions
Semi/Non Modular
PCIE 8pin and PCIE 6pin Connectors Support
120mm Thermal Temperature Control Fan
80 Plus | Bronze |
Cybenectics Efficiency Level | / |
Cybenectics Noise Level | / |
From Factor | ATX 12V |
Dimensions | 140mm×150mm×85mm |
Fan Bearing | 120mm Fluid Dynamic Bearing |
Cable Information | All Cable in Flat(Visible from housing) |
AC Input | Full Range |
Protection | OVP,UVP,SCP,OPP,NLO,SIP |
Certification | Energy Star,RoHS,ErP,CE,FCC,REACH,UKCA |
Cable Type | Connectors Per Cable | Length | Number of Cable Included | ||
MB(20+4 pin) | 1 | 450mm | 1 | ||
CPU(4+4 pin) | 1 | 500mm | 1 | ||
PCIE(6+2 pin) | 2 | 500mm+150mm | 1 | ||
SATA | 3 | 400mm+150mm+150mm | 2 | ||
Molex | 3 | 400mm+150mm+150mm | 1 |
